Cub Cadet RZT-S Professional Shop Manual

Brakes and Drive System
39
3. Disconnect both of the drive control rods from the
transmission control arms using a pair of 9/16”
wrenches. See Figure 4.34.
4. Start the engine and advance throttle to maximum
RPM.
5. Release the parking brake.
6. Observe the movement of both rear wheels.
See Figure 4.35.
• If there is no wheel movement, the hyrdo transmis-
sions are in neutral and don’t need to be adjusted.
Skip ahead to step 13.
• If one or both rear wheels move, the hydro trans-
missions need to be adjusted. Continue on to
step 7.
Figure 4.34
Drive control rods
Figure 4.35
No movement
