8-20
8. OPERATION
Sc2450 Operator's Manual
■ Hydro Static Transmission (HST) Pressure Release Lever
Hydraulic pressure in the Hydro Static Transmission
(HST) brakes the axles when the engine is not
running, so that the tractor cannot be moved.
When the hydraulic pressure in the transmission is
released by pressing the Hydro Static Transmission
(HST) pressure release lever, the tractor can be
moved.
To move the tractor, observe the following
procedure:
1. Make sure that the engine is stopped.
2. Tilt the seat forward.
(A) Seat
3. Fully depress the Hydro Static Transmission
(HST) pressure release lever.
(A) Hydro Static Transmission (HST) pressure
release lever
4. Disengage the parking brake.
5. Move the tractor.
6. After moving the tractor, fully pull up the Hydro
Static Transmission (HST) pressure release lever.
7. Engage the parking brake securely.
3016488
(A)
3016486
(A)
1A7880-65380
To Next Page
