9. POWER TAKE OFF (PTO)
Sc2450 Operator's Manual
8. While watching the instrument panel, adjust the
engine speed suitable for operating with the
throttle control lever.
(A) Throttle control lever
NOTE
●When the engine speed is 3300 min
-1
(rpm), the
Mid-Power Take Off (PTO) rotates at
approximately 2100 min
-1
(rpm).
●When the engine speed is 3100 min
-1
(rpm), the
Rear Power Take Off (PTO) rotates at
approximately 540 min
-1
(rpm).
■ Disengage the Power Take Off (PTO)
1. Run the engine at a low speed.
2. Push in the Power Take Off (PTO) switch to set it
to the OFF position.
(A) Power Take Off (PTO) switch
(a) ON position
(b) OFF position
3014903e
(A)
3014919c
(A)
(b)
(a)
