27
0306 / 13 013 497A
A1 Control and safety unit
B10 Measuring bridge [µA DC]
F6 Air pressure switch
F12 Thermal relay of the protection device
K1 Fan motor protection device
K5-K6-K7 Time delay units
M1 Fan motor
SA1 The control unit displays :
- program cycle,
- faults : red light illuminated and
reset pushbutton
TC Control panel
T1 Ignition transformer (hidden)
Y10 Servomotor
9 End-piece
15 Cover
102 Motor / pump
113 Air box
General information
Overview
EN
