NOTCH THRESHOLD Threshold value (in percent) for the recognition of the presence of notch by the notch
sensor:
30% 70%
40%
D
80%
50% 90%
60%
NOTE: If the “Notch/B.Mark position” parameter is disabled, this parameter is not printed.
NOTCH DISTANCE “Notch Distance” is the minimum distance (in mm) between the upper edge of ticket and
The numeric value of the distance is made up with the following four parameters for the
setting of three digits (two for the integer part of the number, one for the decimal part
and of the sign):
NOTCH DISTANCE SIGN
Sign setting:
+
D
= positive distance
- = negative distance
NOTCH DISTANCE [mm x 10]
Setting the digit for tens:
0
D
2 4 6 8
1 3 5 7 9
NOTCH DISTANCE [mm x 1]
Setting the digit for units:
0
D
2 4 6 8
1 3 5 7 9
NOTCH DISTANCE [mm x .1]
Setting the digit for decimals:
0
D
2 4 6 8
1 3 5 7 9
NOTES:
For example, to set the notch distance to 15 mm, modify the parameters as follows:
Notch Distance Sign = +
Notch Distance [mm x 10] = 1
Notch Distance [mm x 1] = 5
Notch Distance [mm x .1] = 0
If the “Notch/B.Mark Position” parameter is disabled, the parameters for the “Notch Distance” are not printed.
66
