VKP80III ETH
ETHERNET
24Vdc
LOW
PAPER
I/O
HUB PC
ETHERNET
CrossOver
standard cable
ETHERNET UTP
standard cable
(pin-to-pin)
PC
USB device
USB
standard cable
Power supply
Power supply
cable (optional)
External
low paper
External
device
ATTENTION:
In some using conditions, we recommend the installation of a ferrite core on the power supply cable.
