11 88
ETHERNET INTERFACE
Female RJ45 connector
J23
1 RX +1
2 +3.3V
3 RX -1
4 TX +1
5 +3.3V
6 TX -1
7 n.c
8 GND
9 +3.3 V
10 LED-LNK
11 +3.3 V
12 LED-LAN
13 SH1
14 SH2
NOTES:
- For 10Base-T connection:
LED FUNCTION
LED-LNK Link (yellow color): the LED lights up when a connection is active
LED-LAN Rx/Tx: (green color): the LED lights up when occurs a data reception or transmission
- For 10/100Base-TX connection:
LED FUNCTION
LED-LNK
reception or transmission
LED-LAN The LED light (green color) on when occurs a 100 Mbit connection and off when occurs a 10
Mbit connection
The device automatically recognizes the type of connection (cross or pin-to-pin).
The pinout shown in table represents the input signals to component J23 before the isolation voltage transformer
(through-hole pin).
32
