VKP80III REAR
Connect the power supply cable to an external power supply unit.
Connect the power supply cable to the device.
Use the type of electrical power supply indicated on the label.
The green status LED turns on and the device is ready.
Power supply cable
(optional)
EXTERNAL POWER SUPPLY
(OPTIONAL)
IN DC 24V 1.5A
RS232
24Vdc
Power supply cable (optional)
1
2
3
