VKP80III ETH
Connect the power supply cable to an external power supply unit.
Connect the power supply cable to the device.
Use the type of electrical power supply indicated on the label.
The green status LED turns on and the device is ready.
Power supply cable
(optional)
EXTERNAL POWER SUPPLY
(OPTIONAL)
IN DC 24V 1.5A
Power supply cable (optional)
ETHERNET
24Vdc
1
2
3
