Check that there are no scraps of paper at the points indicated in fi g.1.9 on the paper infeed and outfeed
openings, on the cutter opening or the ejector roller. If there are, remove the scraps before proceeding with
any other operation.
WARNING
Periodically remove accumulated paper dust from the upper plastic slide (A) and the area
around the paper outfeed sensor (D). Clean carefully the paper sensor (B) and the notch sensor
(C). To clean, do not use harsh chemical solvents; the use of a soft, alcohol-moistened cloth and
pneumatics air is recommended (see fi g.1.10)
3
4
AA
B
B
C
C
D
D
(Fig.1.9)
(Fig.1.10)
1. INSTALLATION AND USE
1-8 VKP80II User Manual
