PRINTER FEATURES
VKP80II is the latest generation of ATMs, Kiosks and Ticket Printers with high printing speed 220mm/sec and
a very small footprint; it’s equipped with a 204 dpi (8 dots/mm) thermal printing mechanism.
In addition to normal printing functions, the printer offers a wide array of special features:
High speed printing:•
Easy paper changing (automatic paper loading).•
Paper width 60/76/80/82.5mm, adjustable by the user.•
Bar code UPC-A. UPC-E, EAN13, EAN8, CODE39, ITF, CODABAR, CODE93, CODE128 and CODE32.•
3 standard and international character set fonts.•
Defi nition of function macros for automatic operation re-call.•
Graphic mode printing.•
Print density (-50% to +100%).•
Serial interfaces RS232: (from 1200 to 115200 bps)•
Interfaces: RS232-USB•
High reliability autocutter.•
Illuminated paper mouth.•
Paper pre-tensioner system for high capability paper roll.•
Double function ticket presentation: “ejecting” and “retracting”.•
Sensors: paper end, ticket present, black mark, head temperature, opening of printing unit (near paper •
end on roll support is optional).
PRINTER DESCRIPTION
The printer (fi g.2) is comprised of a metal frame, printing mechanism, a cutter and an ejector.
Located on the keypad are the following keys: FORM FEED (1), LINE FEED (2) and status LED (3).
3
2
1
High Quality 80 mm/sec
Normal 180 mm/sec
High speed 220 mm/sec
(Fig.2)
INTRODUCTION
User Manual VKP80II 3
