A.1 ACCESSORIES
A.1.1 Power Supply
The fi gure below illustrates the power supply provided by Custom to be used for printer operation.
95.0
CN1
9.0
+V
+V
-V
-V
FG
N
L
5
95.0
120.0
4 - M3 - P 0.5
4.5
5
6.5
3
3
193.0
5.5
62.0
< 8
0.1
0.15
0.25
0.4
0.8
1.5
0.3°
B
8 25
25 80
80 250
250 800
800 2600
ANGULAR
TOLERANCE
RANGE
Note : Dimensioni in mm
20.0
10.0
7.03.5
10
18.0
198.0
158.0
3 - M3 - P 0.5
6.5
9.5
38
9.0
13.5
3.4 HOLE
PPSPS-100-24V Switching power supply 24V 100W
Input specifi cation Input voltage 85V ÷ 264V
Current 0A ÷ 4.5A
Input frequency 47Hz ÷ 63Hz
Output specifi cation Output voltage 24V
Output current 0A ÷ 4,5A
Effi ciency 80%
Environmental condition Operating temperature 0°C ÷ 70°C
Humidity 20% ÷ 85% Rh (w/o condensation)
Storage temperature / Humidity -10°C ÷ 75°C/
10% ÷ 95% (w/o condensation)
Protection devices: Shortcircuit, overload and overvoltage.
(Fig.A.1)
(Tab.A.1)
