3.1 TECHNICAL SPECIFICATIONS
Table 3.1 gives the main technical specifi cations for the 204 dpi printer model.
Print method Thermal, fi xed head (8 dot/mm)
Resolution 204 DPI (8 dot/mm)
Paper specifi cations
Type of paper Thermal rolls
Heat-sensitive side on outside of roll
Recommended types of paper from 55 g/m
2
to 110
(1)
g/m
2
(KANZAN)
Width from 60
(2)
to 82,5 mm
Internal roll core diameter 25mm
External roll diameter
max Ø180 mm
(3) (4)
OPTIONAL
OPTIONAL
OPTIONAL
Upper attachment
Rear attachment
Lower attachment
max Ø170 mm
(5)
max Ø180 mm
(5)
max Ø180 mm
(5)
Core type Cardboard or plastic
Sensors Head temperature, black mark, paper presence, ticket presence on
output, opening of printing unit, (near paper end on roll support is
optional)
Printing mode Straight, 90°, 180°, 270°
Printing format Height / Width from 1 to 8, bold, reverse, underlined, italic
Character fonts PC437, PC850, PC860, PC863, PC865, PC858.
Available interfaces RS232 USB
Baud rate From 1200 to 115200 bps
Receive buffer 16 Kbytes
Flash memory 384 Kbytes
Graphics memory 2 logos of 608 x 862 dots (for 80/82,5mm paper width)
Printing Driver Windows
TM
95, 98, ME, NT4, 2K, XP, Linux
Dimensions
(5)
Length [mm] =
Height [mm] =
Width [mm] =
115
115
115
Weight
(5)
2117 gr.
Printing speed
High quality 90 mm/sec
Normal 120 mm/sec
High speed 140 mm/sec
NOTE:
(1)
For paper from 90 to 110 g/m
2
enable the dispenser continuous mode:
$1D $65 n [m]
(2)
For ticket width = 60 mm do not exceed a max length of 250 mm.
(3)
Referred to model without paper holder support.
(4)
It’s better to use an external shock absorber for rolls with a diameter higher than or
equal to 100 mm.
(5)
Referred to model without paper holder support.
(Tab.3.1)
3. TECHNICAL SPECIFICATIONS
User Manual VKP80II 3-1
