Power supply 24 Vdc ± 10%
(optional external power supply)
Absorption (current setting = Normal)
Stand-by 0,1 A
Medium (50% dot ON) 2,2 A
Environmental conditions
Operating temperature 0°C - 50°C
Relative humidity 10% - 80% w/o condensation
Storage temperature / Humidity -20°C - 70°C / 10% - 90%
OPTIONS Roll holder support
Emulation ESC/POS
TM
Character density 11 cpi 15 cpi 20 cpi
Number of columns 88 123 160
Chars / sec 1760 2460 3200
Lines / sec 20 20 20
Characters
Normal 2,25x3 1,625 x 3 1,25 x 3
Retracting function
Ticket length Ticket presentation
70 mm 10 mm
80 mm 10 mm - 30 mm
80 mm - 220 mm 10 mm - 30 mm
Ejecting function
Ticket length Ticket presentation
70 mm 10 mm
> 80 mm 10 mm - 30 mm
350 mm
(6)
10 mm - 30 mm
NOTE:
(6)
Maximum length recommended to guarantee the printer effi ciency.
3. TECHNICAL SPECIFICATIONS
3-2 VKP80II User Manual
