7/38
CybTouch 8 P User Manual
Sep.
2019
V2.1
Touchscreen
Calibration
As a tall operator will tend to touch higher than a smaller one on the screen, this function
allows the calibration of the touch screen, and also makes sure that it is operating
correctly.
Use your finger or the plastic tip of a pen to calibrate the
Touchscreen. Never use sharp objects as this will damage the screen.
RFLink
When activated, this function allows communication between the CybTouch and a laptop
computer, onto which Cybelec’s RFLink dongle is plugged in. This function’s default status
is off, and it is automatically reset to off every time the NC is turned on.
Clear indexation
When activated, this function clears the index and the machine will search for them, as
it does when turning the power on, allowing the operator to re-index its machine without
turning it off.
Set Clock
Allows the user to set the time and date on the CybTouch.
Touch the eld you
want to modify
Use the up and down
arrows to modify the
selected eld
Setting inStructionS:
Simply follow the instructions on the page to calibrate the touchscreen.
Brightness xx%
Eco xx%
Here the brightness of the screen for normal mode and Eco mode can be defined:
1. Touch the mode for which you want to modify the brightness.
2. Use the buttons to set the brightness.
