24/38
CybTouch 8 P User Manual
Sep.
2019
V2.1
7. Touch the numerical value next to the angle icon , and enter the value for the
first bend you wish to create (here 90°).
8. Touch the numerical value next to the segment length icon , and enter the value
for the first segment you wish to create (here 35.00 mm).
bendinG and correcTionS
All program corrections are made in the Bend Numerical Page (see page 14). According
to his preferences, the operator can choose to execute all the steps of the program
one after the other, making corrections along the way. Or he can choose to apply all the
corrections necessary to the same step before moving to the next one using the Semi-
Automatic mode.
Corrections can be made to:
• The angle (Y-axis, see Angle Correction, page 25).
• The back gauge position (X-axis, see Back gauge Correction, page 25).
This dimension is the external dimension of the flange, calculated according
to DIN 6935. If you want to enter the position of the flange manually, touch this
icon . It will switch to this one .
9. Add the next bend to the program by touching .
10. Proceed in the same manner to create the other segments of the part.
11. Go to the desired step touching the Current step (sequence) number (see page 14)
or using this button.
12. Start the hydraulic pump motor (by pressing this button if available. It turns red
when the motor is running).
13. Press the button to position the machine according to the data that were just
entered.
14. When the machine is ready to bend, a button is displayed.
15. If you want to repeat the same step in order to apply all the necessary corrections to
it, switch to the Semi-Automatic mode.
16. Press the foot switch to execute the bend.
