20/38
CybTouch 8 P User Manual
Sep.
2019
V2.1
To be allowed to save a tool, a level 2 password is required.
We recommend that you follow the naming conventions explained in Naming
Tools (see page 22).
9. Touching the button brings you back to the program page, with the punch you
just saved being selected and ready to be used.
dieS
Bend Numerical Page →
Setting inStructionS:
Selecting a die is the same as selecting a punch; simply browse through the existing dies
in your library using the arrows buttons, and then return to Bend Numerical Page.
Die mounting direction
Return to Bend
Numerical Page
Basic die data
Browsing through
existing dies
Die name
5. Touch the button to invert the punch if necessary.
6. Touch the punch name (here 55_N).
7. Touch Save punch to overwrite the existing tool or Save punch as if you want to
save your tool under another name.
8. Enter the name of the new punch using the alphanumerical keypad.
