The More page displays parameters related to the part, and depending on the CybTouch
configuration and the type of action performed, it also displays various settings for the
current bend.
Available
functions on the
More page
More paGe
Bend Numerical Page →
Tooling management
When deactivated (grayed), this icon disables the Punches (see page 19) icon and
the Dies (see page 20) icon from the Bend Numerical Page (see page 14) (see also
Bending without Tools Management, page 26).
Tooling management
Back gauge retraction
The back gauge retraction can be activated/deactivated using this icon. It is possible to
modify the value by touching it. This is a sequence parameter, meaning it can be modified
with each step of the program.
Back gauge retraction
Next step
Return to Bend
Numerical Page
Material thickness
Material sigma
Bending length
Dwell time
Crowning
Opening (TDC)
Access to more functions
Step bending
Force
Material
Force
The force is automatically calculated by the CybTouch, according to the Material, the
Material thickness, the Material sigma and the Bending length. The value can also be
manually modified here.
