17/38
CybTouch 8 P User Manual
Sep.
2019
V2.1
Back gauge manual control
Activating this parameter gives manual control over the back gauge movement. This
means the operator must personally give the start to the back gauge movement, using for
example the foot switch or the start button.
Bending length
This parameter defines the width of the sheet metal part that will be pinched between the
tools. It is used to calculate the bending force.
If this parameter is not activated (gray), the CybTouch will not calculate the
bending Force and the Crowning.
Material thickness
The default thickness, defined in Materials
(see page 8), is automatically displayed
when changing material. It is however
possible to change it simply by touching
this icon.
If on the other hand, the parameter
Predened thickn. (see page 8) is set
to yes, a touch on this icon will open a
numerical pad as show to the right, where
the operator will be able to select directly
one of the predefined thicknesses.
This is a part parameter.
Material
This is not a sequence parameter, but of course a part parameter. Each touch on the
material’s name selects the next available from the list of Materials (see page 8).
Predened thicknesses
Touch here to manually
insert a thickness
