32/38
CybTouch 8 P User Manual
Sep.
2019
V2.1
MSG nr. MeSSaGe deScripTion
W17 Enter the measured angle This message is displayed when the operator must enter the
physically measured angle value in the Bending and Corrections
page.
W18 Empty field Operator did not enter a value.
W19 24V I/O power on 24V to the inputs/outputs is now available.
W20 Please select a field This message is displayed when trying to set the time (see Set
Clock, page 7) and no field (minute, seconds, etc.) has been
selected.
W21 Set seconds
In the Set Clock (see page 7) page, when the corresponding
field is selected, indicates that it can be set using the up and
down arrows.
W22 Set minutes
W23 Set hour
W24 Set day
W25 Set month
W26 Set year
W29 End of list This message is displayed when reaching the end of the list in
one of the different menus .
W30 Serial number from 100’000
thru 231’071
This message appears only when entering the serial number. It
indicates the range of the number to be entered. Attention, this
operation is normally done at the factory, with a serial number is
related to the options installed on the machine. Do not change it!
W31 New option code When installing a new option in the Service Page (see
page 11).
W32 Data entry in progress Operation impossible: data entry in progress. Wait until the data
is entered to try again.
W33 Indexation in progress Operation impossible: indexation in progress. Wait until the
indexation is finished to try again.
W34 RFlink disconnected When the RFLink connection to a laptop has been shut down
from the latter.
W35 Access not allowed Operator needs another level password.
W37 Moving direction has been
inverted
Wizard message: Rotary direction of the motor has been
changed.
W38 Counting direction has been
inverted
Wizard message: Counting direction of the axis has been
changed.
W39 Moving and counting
directions have inverted
Wizard message: Both the rotary direction of the motor and the
counting have been changed.
W40 OK Indicates a cycle or operation has properly ended.
W41 No movement executed
Axis Wizard message: Operator pressed but no movement
was made.
W45 Enter unlock interface
password
This message is displayed when parameter P02.04 Level 0 Lock
HMI is set to yes and the screen is touched.
W46 Enter password level 1 or
greater
This message is displayed when a password of level 1 or higher
is needed to execute a specific operation.
W47 Enter password level 3 This message is displayed when a password of level 3 or higher
is needed to execute a specific operation.
W48 Enter new password
These messages are displayed when changing passwords.
W49 Confirm new password
W50 Enter password for backup This message is displayed when trying to create a backup.
W51 Enter password for restore This message is displayed when trying to restore a backup.
