8. A yellow pop-up is displayed, in
which it possible to:
• Activate (and deactivate) a
special tool by touching its icon
and select it from a list by
pressing ???
• Change the value of the radius
(see also Step bending) and
define how many steps the NC
will make to execute it.
9. A small More icon shows that
something special is programmed
on the bend.
10. To remove the icon (and special
parameters), return to the yellow
popup, touch all the activated
functions to make them turn gray,
and select OK.
11. Once all the segments and angles are adjusted, press this button to access
Bend Sequencing.
All program corrections are made in the Bend Numerical Page. According
to his preferences, the operator can choose to execute all the steps of the program
one after the other, making corrections along the way. Or he can choose to apply all the
corrections necessary to the same step before moving to the next one using the Semi-
Automatic mode.
Corrections can be made to:
• The angle (Y1 + Y2, see Angle Correction (Y axis) and/or crowning if available, see
Crowning),
• The back-gauge position (X and R, if available), see Back gauge (X & R axes)
Correction.
The semi-automatic mode allows repeating the same sequence indefinitely. It is used
when the operator wants to apply corrections to his part one bend after another. He can
thus execute the same step until he gets the desired result, before moving to the next
one by means of the button.
The semi-automatic mode is activated (and deactivated) by touching for more than one
second on the button.
