User Manual – CybTouch series
CybTouch Series – User Manual
Command refused because pinch point is
below Y1 and Y2 bottom dead centre
Check the value of the PP correction, and the value of
the BDC correction in the User Preference page.
Command refused because the speed
commutation point is below the pinch point
Command refused because low speed up
speed out of limits
Command refused because speed out of
limits
Command refused because Bottom Dead
Centre Y1 and Y2 are too different
Difference between target values of Y1 and Y2 bigger
than the limit value defined in the machine parameter.
Call you dealer.
Command refused because pinch point is
outside stroke limits
Command refused because beam is moving
Command refused because Bottom Dead
Centre is outside the beam limits
Command refused because beam is in
emergency
For example, beam out synchronism tolerance.
Command refused because Synchronism
controller parameters not in range
Problems with limit parameters (max and min) of the
beam. Contact your dealer.
Command refused because stop is active
Command refused because zero has not
been found yet
Command refused because bend data have
never been loaded
Command refused because beam is in
emergency. Only a manual down of the
upper axis is allowed
Only the axis with the highest position is allowed to be
moved manually down.
Command refused because beam is not at
high end of stroke position
Command refused because the beam is
requested to go to TDC
Command refused because a beam cycle is
not running
Synchronism limit reached, Y1: {0} Y2: {1}
Height difference between Y1 and Y2 bigger than the
limit value defined in the machine parameter. Call you
dealer.
Error with Oil Leakage Control. Cancelling
operation
Beam not indexed, no move
High speed down stopped by safety speed
switch
