5. Touching this icon allows applying a correction to the back-gauge X axis
position.
6. Touching this icon allows applying a correction to the back-gauge R axis
position.
The greyed values next to the back-gauge correction icons are the value calculated
by the numerical control, and thus the values onto which the corrections will be
applied.
The back-gauge positions corrections can also directly be made on the Bend
Numerical Page.
This function allows the operator to run two, or several, part-programs one after another.
This is very handy when one wants to make a three-dimensional part, like a box for
example, or make a final product composed of several parts.
The CybTouch will execute the current program. At the end of the last sequence, instead of
returning to the first sequence of the current program, the CybTouch switches to the
program selected as P+nn (i.e. the next one). It goes on like this, as long as a part is
programmed with a next one.
