Set-point back gauge (R axis – optional)
The value of the vertical position of the back gauge (R axis) is calculated by the CybTouch. It
is displayed in grey. It can however be manually modified but is then displayed in black.
It is possible to restore the calculated value simply by erasing the manually entered
value in the numerical pad . The message “Default/Recalculate” appears at the
top of the screen. Just press validate on the numerical pad.
The lower part of the Bend Numerical Page displays parameters related to the part,
and depending on the CybTouch configuration and the type of action performed, it also
displays various settings for the current bend.
Material
This is not a sequence parameter, but of course a part parameter.
Each touch on the material’s name selects the next available from
the list of Materials.
Material thickness
The default thickness, defined in Materials, is automatically
displayed when changing material. It is however possible to change
it simply by touching this icon.
If on the other hand, the parameter
Predefined thickn. (see page 11) is set to
yes, a touch on this icon will open a
numerical pad as show to the right, where
the operator will be able to select directly
one of the predefined thicknesses.
This is a part parameter.
