If a product is removed, the data contained in the tool fields, the thickness
field and the material information fields continue to be displayed. This saves
the operator from having to reprogramme unchanged data.
P 1 N 1 CY __
Th: 2.00 45.00 Kg/mm²
p/d 1/ 1 CR __/ri 2.78
--MEM-- --POS-- --COR--
90.0°
Y1 293.11 350.92 ____.__
Y2 293.11 351.05 ____.__
X 1 133.91 51.85 ____.__
Q ____ ____
Lmat 5000 TON 78
Rx _ ___ Ext start _
Vy __% __% ΔT _._s
TDC ___ SP ___
F1:___ F2:___ F3:___ F4:__ F5:__ Cr: 41
FIELD OVERVIEW
P
Number of the product in the work memory.
P+
Number of the following product when there is
a sequence of programmes.
N
Bending order (sequence) number to be made
and the total number of bends for the product.
CY
Number of sequence repetitions.
(programmed 0, the sequence is jumped)
Th
Material thickness.
The Greek symbol "Sigma" indicates the
tensile and rupture strength.
This field, as well as those showing the type of
material, can be hidden (see the
preferences
page in the machine parameters).
If this field is hidden, the default value is
steel
45 kg/mm
2
, but other values can be defined in
the ad hoc field in the machine parameters.
p/d
Number of the punch/die pair associated with
the bend to be made.
In the P or D field press
to display the list
of tools.
CREATING A PRODUCT PAGE 9
