Sequence N 3: Face 2 and Leg 1
Sequence N 4: Face 4 and Leg 5
To introduce this bending order:
Fill in the FACE and LEG fields as follows:
P 1 N 1 p/d 1/ 1
BEND 1 2 3 4 5 6 7 8 9 10
1 3 2 4 __ __ __ __ __ __
LEG 0 1 1 5 __ __ __ __ __ __
Press the key.
The system calculates the entire machine program (axes, functions, etc.).
PAGE 48 USER GUIDE DNC 600S
