Sequence N 3: Face 2 and Leg 1
Sequence N 4: Face 3 and Leg 2
Call the bending order page by pressing the
key twice.
Fill in the
and LEG fields as below.
You will remark that the p/d fields are already programmed since we
have already made a calculation before.
P 1 N 2 p/d 1/ 1
BEND 1 2 3 4 5 6 7 8 9 10
4 1 2 3 __ __ __ __ __ __
LEG 0 0 1 2 __ __ __ __ __ __
Press the key.
The system calculates the entire machine program (axes, functions, etc.).
APPENDIX F: PROGRAMMING WITH L-ALPHA PAGE 51
