13
2. Advanced Power Management
Intelligent PDU Web Interface
PDU Tab > Status > Outlet*
*The above Outlet Status Page is available for Switched Metered by Outlet Series only.
Item Definition
HOST/GUEST#
Select the role of PDU (HOST or GUEST#) if PDUs are daisy
chained. Up to 3 GUEST PDUs can connect to 1 HOST PDU.
Status The on/off status of each outlet.
Load (A) Load current of each outlet, measured in Amps.
Load (kW) Load power of each outlet, measured in Kilowatts.
Peak Load (kW)
The maximum load current recorded and the time of occurrence.
Users can reset the value to zero at Power Restore in
PDU Ta b >
Manager > Outlet
.
Energy (kWh)
To ta l energy consumed by connected equipment of each outlet
since the last reset. The reset can be set in
PDU Tab > Manager >
Outlet
.
