Cybex Sport+ Treadmill Owner’s and Service Manual
ITEM PART NO. DESCRIPTION
NO.
121 HS-16940 Screw, Sems 10-32 x 3-8 PNHD ext, BL ZN
122 FS-16990 Plate, Switch, Power On-Off
123 SW-10523 Switch, On-Off
124 HS-41187 Screw, 8-16 x 5-16 Plastite
125 HS-15706 Screw, 8-16 x .50 PNHD STL BLK Phil
126 HX-17711 Plug, Hole Plastic 7-16 Black
127 ET-17165 Tab, Faston .250 Series AMP, International Only
128 DE-16784 Decal, Side Stripe
129 DE-17714 Decal, Cybex, Side
130 HX-17822 O-Ring
NS LT-18115-4 Owner’s and Service, Manual Cybex Sport+, English
NS LT-17718 Poster, Assembly
NS LT-18129 Warranty Sheet, Cybex Sport+, Pink
NS HX-00438 Hex Key 3-16"
NS EH-16954 Cap, Motor Brush Access, Round
NS EH-16955 Cover, Motor Brush Access
NS SK-17269 Brush Kit, Pair, High Voltage, 2.5 and 3.0hp Leeson Motor
NS CK-18942 Handrail Extension Kit, Left and Right - Complete kit with instructions
NS CK-19088 Handrail Extension Kit, Left Only - Complete kit with instructions
NS CK-19089 Handrail Extension Kit, Right Only - Complete kit with instructions
NS HS-16921 Bolt, 5/8-11 x 4.75, Black Zinc - Bottom hardware
NS AX-16273 Clamp Assy, Handrail Ext.
NS HX-16852 Grip, Handrail Extension
NS HS-16935 Screw, Set 1-2 13 x 1-2, Knurl pt - Top Hardware
NS FT-16278 Spacer, Handrail Ext - Bottom hardware
NS AW-16572 Jumper, Switch-Filter, White
NS AW-16938 Jumper, Switch-Filter, Black
NS AW-16578 Jumper, Filter-cntl, White
NS AW-16579 Jumper, Filter-cntl, Black
NS AW-16561 Cable, Univ. Tread Display
NS AW-17706 Cable, Contact HR Grip
NS AW-17732 Cable, 4” Ribbon C-SAFE
NS DE-18101 Cybex Sport+ Decal for Side Extrusions
NS CN-10418 Connector, Molex (Placeholder)
NOTE: NS = Not Shown
Service
Page 7-42
