Cybex Sport+ Treadmill Owner’s and Service Manual
ITEM PART NO. DESCRIPTION
NO.
58 SK-17253 Lower Control Assy, 115V
58 SK-17252 Lower Control Assy, 230V
58 SK-17251 Lower Control Assy, 230V 50Hz, International use only
59 DE-16608-4 Brush Replacement Gauge, English
60 DE-16610-4 Label, Error Codes, English
61 DE-16609-4 Label, Service Schedule English
62 DE-19198 Decal, Logo
63 DE-17691-4 Label, User Precautions, 15 x 1.3”
64 DE-18100-4 Label, Start Instructions, Profiles, English
65 DE-18135-4 Label, HR Zone, English
66 EH-16977 Fan, Drive Motor, Leeson
67 AW-17704 Motor Ground Wire
68 HW-40004 Washer, Wavy
69 AX-17762 Motor Base Plate Assy
70 HS-16849 Screw, 5-16-18 x 2.0LG H x HD,GR5,Tap
71 HW-00165 Washer, Lock Ex 5-16 Zinc
72 Removed
73 HB-16426 Bushing, Flanged,1.0ID x 1.12OD x .75LG
74 HX-16425 Ring, Retaining Ext Crescent
75 FT-16352 Shaft, Motor Mount
76 AW-16830 Cable, Opto Sensor, Armored
77 HW-10772 Washer, Flat No. 4
78 HW-10761 Washer, Lock Ex No.6 Zinc
79 HS-00156 Screw, 4-40 x 0.62 Pnhd Phil
80 AF-17792 Clamp, Motor Drive (includes nut)
81 SK-17246 Motor, 3.0 Hp 110v, PMDC 3500RPM GR
81 SK-17245 Motor, 3.0 Hp 220v, PMDC 3500RPM WH
82 DE-16542 Disc, Speed Sensor
83 FM-16463 Flywheel, Drive Pulley Machined
84 HX-11593 Key, Ansi Square 3-16 x 1 3-16
85 HW-16966 Washer, Flat .280 x 1.0 x .125 Steel, Zinc
86 HW-00180 Washer, Lock Split 1/4
87 HS-15757 Bolt, Tap 1/4-28 x 1.0 H x HD PLTD
88 PC-16379 Cover, Junction Outer, Right, (Choose a Standard or Custom Color)
89 PC-16380 Cover, Junction Inner, Right, (Choose a Standard or Custom Color)
90 PC-16328 Cover, Junction Inner, Left, (Choose a Standard or Custom Color)
91 PC-16327 Cover, Junction Outer, Left, (Choose a Standard or Custom Color)
92 DK-16932 Deck, Plywood 23.3 x 51.5 x 1.0 (Double Sided)
93 BD-16853 Belt, Running, 20.63 x 58 Commercial
94 HW-00431 Washer, 1-4 x .75 x .062 Zinc
95 HS-16628 Screw, .25-20 x 1.5 Hxhd Grade 8
96 AL-16245-1 Roller, Front Assy
97 AL-16235-1 Roller, Rear Assy
98 BD-16829 Drive, Belt, 8 Rib
99 PL-17659 Console, Back, Plastic
100 DE-17712 Decal, Logo, Cybex Intl, 9 x 7”
101 AC-18125-4 Entire Console, Cybex Sport+, English
101 PL-17658 Front Console, Plastic
102 SW-17212-4 Switch Membrane, Cybex Sport+ Top, English
103 SW-17187-4 Switch Membrane, Cybex Sport+ Bottom, English
104 AX-16944 Lanyard, E-stop Assembly
105 PL-17686 Tab, Bookholder
107 AD-16560 PCA, Handset Display with w/o Heart Rate
108 AD-18130 PCA, Cybex Sport+ Display Board, 4 Layer
109 FS-16841 Mount, E-stop Magnet
110 AD-17690 PCA, CSAFE Port Board, W-TVS
111 EC-17763 PCA Salutron Serial Output
112 AW-17707 Cable, CHR to display with ferrite
113 AF-17684 Handrail, Weldment
114 SK-17827 Kit, Assembly, Contact Heart Rate Grip, Pair
115 HX-17788 Double-sided Tape
116 HX-15499 Grip Handlebar
117 HX-16931 Clamp, Cable, 5-16 dia Standard
118 HS-10716 Screw 4-40 x 0.38 PNHD Phil
119 EH-00472 Wire Tie Ty-23M
120 HX-17696 Clamp, Cable 5-8 Dia.
Service
Page 7-41
