Cybex Arc Trainer Owner’s & Service Manual
Page 7-46
89 1 AF-16663 Handrail
90 1 PP620001 Back Plastic Console
91 4 BB030024 Grip
92 1 PP620002 Rear Console
93 1 YD000025 Tape
94 6 HX-17017 Tube End Plub 1.50 Tube OD
95 1 PN140000 Cable Clamp 5-16 Dia.
96 10 HT552512 Screw, 8-16 x .50 Type WB PNHD PHI
97 8 HJ542514 SEMS, 8-32 UNC x .62 PNHD Phil Pl
98 1 HJ542510 SEMS, 8-32 x .38 PNHD Phil Ext
99 1 AW-17007 Cable Display Upper Arc Trainer (not shown)
100 2 CM000238 Anti Static Printed Label (not shown)
101 1 AX-17154-4 600A Front Console Assembly
102 1 AD-17095 Arc Display Board PCA
103 1 AD-17106 CSAFE Port Board With TVS PCA
104 1 BB030021 Salutron Bracket Ground
105 1 BB030022 Salutron Bracket
106 1 CM000239 Handset Logo Decal
107 1 EE000001 Handset Display With WHR PCA
108 1 EE000002 Heart Rate Monitor Assembly PCB
109 1 EL000000 Molex Connector 22-01-3037
110 1 EW600001 3 Pin Cable HR Jumper W-FER (not shown)
111 1 EW600002 CHE Cable Grip Assembly (not shown)
112 1 EW600004 CSAFE Jumper Ground (not shown)
113 3 HM522510 PN HD Phil SC No 4-40 x .38
114 1 HS047300 Ext Tooth Lockwasher No 10 (not shown)
115 10 HT552509 Tap SC No 8-16 x .31 Plastite Pn
116 1 PP620000 Top Console
117 1 SW-17005-4 600A Switch Membrane Top
118 1 SW-17006-4 600A Switch Membrane Bottom
ITEM QTY PART NO. DESCRIPTION
Handrail Assembly
