! CAUTION: Do not pinch your fingers between the belt and pulley during this procedure.
D. Use your hand to slowly turn the flywheel and ensure that the belt is on straight.
12. Attach the left crank cover.
A. Place the crank cover in position.
B. Using a Phillips head screwdriver, attach the three screws removed in step 5A. See
Figure 6.
13. Secure the left side cover.
A. Using a Phillips head screwdriver, attach the six screws and six washers removed in
step 4A.
14. Attach the left connecting rod.
A. Place the left connecting rod in position.
B. Using a 3/16” hex key, attach the screw removed in step 3A. See Figure 4.
15. Attach the access cover.
A. While being sure not to pinch any cables, place the access cover in position.
B. Using a Phillips head screwdriver, attach the four screws removed in step 2A. See
Figure 2.
16. Test the unit for proper operation.
A. Connect the power cord into the power outlet.
B. Turn the main power switch above the power inlet to the on (I) position.
C. Operate the unit to verify proper operation.
Elevation Motor
Tools Required
• Phillips head screwdriver
• 3/16” Hex key
• 7/16” Socket wrench
• 3/8” Nutdriver or socket wrench
• 9/16” Open end wrench
• 9/16” Socket wrench
! WARNING: Disconnect the power cord before beginning this procedure. Keep wet
items away from inside parts of the unit. Electrical shock could occur even
if the unit is unplugged.
Cybex Arc Trainer Owner’s & Service Manual
Page 7-16
