Cybex Arc Trainer Owner’s & Service Manual
Page 7-15
Table of Contents . . . . . . . . . iii
7 Service
Warnings/Cautions . . . . . . . 7-1
Test Mode . . . . . . . . . . . . . . 7-2
LED Functions . . . . . . . . . . . 7-3
Key Functions . . . . . . . . . . . 7-3
Error Codes . . . . . . . . . . . . . 7-4
Speed Sensor Adjustment . 7-5
Drive Belts . . . . . . . . . . . . . . 7-7
Eddy Current Brake. . . . . . 7-13
Elevation Motor . . . . . . . . . 7-16
Power Switch . . . . . . . . . . 7-20
Upper Pillow Blocks . . . . . . 7-22
Lower Pillow Blocks . . . . . 7-26
Pedal Arm & Linkage Arm . 7-28
Lower Control Board . . . . . 7-29
Upper Display Board . . . . . 7-31
Contact Heart Rate Board. 7-33
CSAFE Board . . . . . . . . . . 7-35
Upper Display Cable . . . . . 7-36
Lower Display Cable . . . . . 7-38
Display Overlays . . . . . . . . 7-41
Parts List . . . . . . . . . . . . . . 7-43
Exploded Views. . . . . . . . . 7-45
Schematic . . . . . . . . . . . . . 7-51
B. When the flywheel is cool, remove the secondary belt from the eddy
current brake.
C. Using a 3/16” hex key, first remove the two bottom screws securing the
eddy current brake in place. See Figure 16.
D. Support the brake with your hand while removing the two top screws so
that it does not fall.
E. Remove the eddy current brake from the unit. NOTE: Cybex may want
the old parts for evaluation. Call Cybex Customer Service to get an RMA
number.
9. Attach the new eddy current brake.
A. Locate the holes on the eddy current brake. Notice that there are four
threaded holes and four non-threaded holes. See Figure 16.
B. Locate the two pins on the brake mount bracket. See Figure 16.
C. Orient the brake with the cable away from the unit. See Figure 16.
D. Slide the brake pulley into the secondary drive belt.
E. Place the two pins in any of the non-threaded holes on the bracket.
NOTE: Do not place the pins in threaded holes.
F. Confirm that the brake is flat against the bracket and that the drive belt
is straight on the pulley. NOTE: Continue to support the brake during
the next step.
G. Using a 3/16” hex key, first tighten the two top screws securing the
eddy current brake. See Figure 16.
H. Tighten the two bottom screws securing the eddy current brake.
10. Connect the brake cables.
A. Locate the J1 and J2 fast-ons on the lower board.
B. Connect the brake cables to the lower board at J1 and J2. NOTE: It
does not matter which brake cable connects to J1 and J2.
C. Place the lower board shield in position and snap it in.
11. Tension the drive belt.
A. Confirm that the secondary drive belt is straight and centered on the
lower pulley. See Figure 12.
B. Confirm that the two spacers are still in place under the lower pivot shaft.
C. Using a 7/16” socket wrench, tighten the two screws on the lower pivot
shaft.
