Cybex Arc Trainer Owner’s & Service Manual
Page 7-28
7. Secure the side covers.
A. Place the two side covers and gasket in position.
B. Using a Phillips head screwdriver, attach each side cover with the six screws and six
washers removed in step 4A.
8. Attach the connecting rods.
A. Place each connecting rod in position.
B. Using a 3/16” hex key, attach each connecting rod with a screw removed in step 3A.
See Figure 4.
9. Attach the access cover.
A. While being sure not to pinch any cables, place the access cover in position.
B. Using a Phillips head screwdriver, attach the four screws removed in step 2A.
Pedal Arm & Linkage Arm
NOTE: The pedal arms and linkage arms are removed in the same way. This procedure can be
used for both.
Tools Required
• Phillips head screwdriver
• 3/16” Hex key
1. Disconnect the external power source.
A. Turn the main power switch above the power inlet to the off (O) position.
B. Unplug the power cord from the power outlet.
2. Remove the arm.
A. Using a Phillips head screwdriver or 3/16” hex key, remove each screw securing the
(appropriate) cap. See Figure 23.
B. Remove the cap.
C. Slide the foot plate off the foot plate shafts (if applicable).
D. Slide the (appropriate) arm off the shaft (or shafts).
3. Attach the new arm.
A. Slide the (appropriate) arm on the shaft (or shafts).
B. Slide the foot plate on the foot plate shafts (if applicable).
C. Using a Phillips head screwdriver or 3/16” hex key, attach cap with the (appropriate)
screw securing the cap. See Figure 23.
