Cybex Arc Trainer Owner’s & Service Manual
Page 7-48
2 1 AX-17156 Front End Assembly
2A 1 AF-16483 Front End
2B 1 AD-16982 PCA Control Board 115V
2C 1 AX-17208 ECB Assembly
2D 1 600A-322 Secondary Drive Belt
2E Removed 11/02
2F 1 BD-16671 Primary Drive Belt
2G 16 HF579000 Panel Fastener 10-24 U Type
2H Removed 11/02
2I 1 EC-17097 Power Outlet IEC320 Module
2J 1 ES000000 Switch On-Off
2K 1 DE-17155-4 Warning Decal
2L 2 HX-17050 Nylon Insulating Bushing
2M 2 HJ582510 SEMS 10-32 x 3/8 pan hd, ext
2N 1 PL-17237-4 Controller Cover
2O 4 PP660010 Single Head Christmas Tree Clip
2P 1 PW-16521 Lower Machined Pulley
2Q 1 FM-16859 Lower Pivot Shaft
2R 2 HS307600 Washer
2S 2 HS308300 Split Lock Washer
2T 2 HS-17145 Hex 1-4-20 x 3.00 Tap 8G
2U 2 FM-17146 10 Rib Belt Spacer
2V 2 BR030221 Retaining Ring
2W 1 DE-17019 Speed Sensor Disc
2X 2 FB030243 Bearing 25M mid x 52M mod 6205
2Y 1 AF-17060 Rocker Arm
2Z 2 HS348300 Split Lockwasher .375
2AA 1 HC701217 HHCS .375 x 1.00
ITEM QTY PART NO. DESCRIPTION
2BB 1 HC700432 Screw 3-8-16 x 2.75 Button
2CC 9 HS347700 Washer USS .375
2DD 1 CW-17063 Tensioner Wheel
2EE 4 HN706300 Nut Keps 3-8-16 Hex Stl
2FF 8 HS-17055 SHCS .25-20 x .75
2GG 4 HC701252 3-8-16 x 5.25
2HH 1 PW-17016 Poly-V Drive Die Cast Pulley
2II 2 AF-16694 Pillow Block Assembly
2JJ 1 HC701214 HHCS .375 x .625
2KK 6 HJ542514 Screw 8-32 x .62 sems
2LL 1 HM522514 Screw #4-40 x .62 Phil Ph
2MM 1 EW600003 Cable Speed Sensor
2NN 1 HS048300 Split Lockwasher
2OO 1 AF-17141 Speed Sensor Bracket
2PP 1 HS047600 Washer
2QQ 1 AW-17099 Power Inlet Blue Jumper (not shown)
2RR 1 AW-17098 Power Inlet Brown Jumper (not shown)
2SS 1 CM000237 Ground Symbol Label
2TT 2 HX-17023 Spring Pin
2UU 3 HJ582512 Tap Sc No. 10-24 x .50 Pn Hd Phil
(220V option only)
2VV 1 AF-16461 Crank Shaft
2WW 1 HS047300 Lockwasher Ext No. 10
2XX 4 HN586300 Keps 10-32 stl
2YY 2 EF000000 Fuse 6Aski-Blo 5 x 20Mm 250V
2ZZ 1 AX-17259 Transformer 200KVA (220V option only)
2AAA 1 600AK003 Arc Trainer Filter Power Input
Module/Power Switch Plate Kit
ITEM QTY PART NO. DESCRIPTION
Front End Assembly
To Next Page
