Cybex Arc Trainer Owner’s & Service Manual
Page 5-8
9. Level the unit.
A. Confirm that the unit is on a level surface. If it is not, use a 9/16” open-end wrench
wrench to adjust the leveling feet up or down. See Figure 9.
10. Connect the power
cord.
A. Plug the power
cord into the inlet
near the on/off
switch. NOTE: Do
not plug the power
cord into an outlet
at this time. See
Figure 10.
11. Visually inspect the
unit.
A. Carefully examine
the unit to ensure
that the assembly
is correct and
complete.
Figure 10
9
Figure 9
Leveling Feet
