CYBEX FT 360 User Manual

Cybex FT 360 Functional Trainer Owner’s Manual
Assembly
Page 6-6
Installing Weight Stacks
! WARNING: Use extreme caution when installing the weight stack. Failure to do so
could result in injury.
NOTE: Two people will be required to perform this procedure.
1. Disconnect lower end of each spring (refer to steps 1A - 1F and Figure 1).
A. Move arm from the #4 position to the #10 position.
B. Firmly grasp lower end of spring.
C. Stretch spring downward with one hand.
D. With your other hand, remove cable end connector from spring (hook).
E. Carefully release spring and set cable down.
F. Repeat steps 1A - 1E to disconnect lower end of other spring.
Grasp spring in this area
Stretch spring downward and
remove hook from cable end
connector
NOTE: Hooks may face either
direction (toward or away from
the other spring).
Figure 1
