CYBEX FT 360 - Installing Shroud

Cybex FT 360 Functional Trainer Owner’s Manual
Assembly
Page 6-13
Figure 11
Front
Back
Installing Shroud
1. Locate shroud (top) cover (see steps 1A - 1B and Figure 1).
A. Locate shroud (top) cover (#33) and four HHCS 10-32 x .625 (#61).
B. Attach shroud (#33) using the four HHCS (#61) located in step 1A. See Figure 1.
61
61
61
61
33
Figure 1
