EZ-USB® CX3 Technical Reference Manual, Doc. No. 001-91492 Rev. *B 16
1.10.1 CX3_SYSTEM_CTRL (Register Address: 0x0002)
This register controls the Sleep and Software Reset functionality for the MIPI CSI-2 block.
This register is used by the CyU3PMipicsiSleep(), CyU3PMipicsiWakeup(), and CyU3PMipicsiReset() APIs.
BIT
15
14
13
12
11
10
9
8
NAME
RESERVED
BIT
7
6
5
4
3
2
1
0
NAME
RESERVED
SLEEP
RESET
Register Field
Bit
Description
RESERVED
[15:2]
RESERVED. Firmware must preserve their settings by reading them,
changing non-reserved bits, and re-writing them.
SLEEP
[1]
Sleep Control:
Places the MIPI CSI-2 block into low-power sleep mode.
0: Normal Operation
1: Sleep Mode
RESET
[0]
Software Reset:
Forces software reset of the MIPI CSI-2 block. Does not clear the
configuration registers.
0: Normal Operation
1: Reset Operation
