Cyrus Pre2 DAC - Installation; Key to the Rear Panel Drawing

Cyrus Pre
2
DAC User Instrucons
5
INSTALLATION
1. MC-BUS system connecon
2. Pre-Amplier output
3. Pre-Amplier output
4. Zone 2 (& tape) output
5. Analogue input 6
6. Analogue input 5
Key to the rear panel drawing
7. Analogue input 4
8. Analogue input 3
9. Analogue input 2
10. Analogue input 1
11. PSX-R/PSX-R
2
connecon
12. Digital input 11 (USB)
13. Digital input 10
14. Digital input 9
15. Digital input 8
16. Digital input 7
17. Headphone socket
18. Power inlet
USE PSX-R ONLY
HEADPHONE
MADE IN ENGLAND
IN-11IN-10IN-9IN-8IN-7
IN-1IN-2IN-3IN-4IN-5IN-6ZONE 2
OUT
PRE OUT 1 PRE OUT 2
MC-
BUS
IN
OUT
a
bcdefghi1)
1!
1@1%1&1* 1$ 1#1^
