HANDHELD UNIT
RF Antenna - Antenna for communication between handheld unit and
collar unit.
Lanyard Attachment Slot - Attachment point for optional lanyard.
USB Connector Port - Connection point to charge handheld unit.
USB Port Cover - Cover protecting USB Port from dirt and debris.
Battery Cover - Cover enclosing the handheld unit's rechargeable
batteries.
Battery Cover Locking Screw - Screw that locks down the Battery
Cover keeping it weather tight. It can be loosened/tightened with a coin
or large flathead screwdriver.
NOTE - Your Handheld Unit will come without the battery installed. To
install the battery:
1. Unscrew the Locking Screw and remove the Battery Cover.
2. Insert the battery with the terminals pointing towards the top of the
Handheld Unit and the positive terminal on the left.
3. Replace the Battery Cover and secure with the Locking Screw.
