Training Screen
Fence Screen
Mark Screen
ICON DEFINITION
Intensity level of selected collar unit in Training
Screen.
Indicates True North in Fence Screen.
Handheld unit icon used to show location of
handheld unit in Fence Screen.
Collar unit icon used to show location and status of
collar unit in Fence Screen (see pg. 45).
Waypoint icon used to show location of waypoint in
Mark Screen (see pg. 58).
LCD SCREEN ICON DEFINITIONS
