CHARGING THE SYSTEM
Charging the Handheld unit
1. The handheld unit can be ON or OFF during charging.
2. Pull out the USB Port Cover to expose the USB Connector Port.
3. Plug the AC Adapter into a standard electrical outlet and connect the
USB charging cable to the handheld unit. The battery icon in the
Systems Information Bar (when powered ON) or a large battery icon
on the LCD screen (when powered OFF) will begin to fill, indicating
that the transmitter is charging.
4. Continue charging until the battery icon in the System Information
Bar is full and green (when powered ON),or the large battery icon is
full and “COMPLETE” shows on the screen (when powered OFF).
5. Disconnect the USB charger from the handheld unit and securely
replace the USB Port Cover.
Charging the Collar Unit
1. Pull out the Charging Port Cover to expose the Charging Port.
2. Plug the AC Adapter into a standard electrical outlet and connect the
charger into the Charging Port. If the collar unit was ON, it will
automatically shut off and go into the charging mode.
3. The LED Light on the collar unit will remain solid RED while charging.
4. Continue charging until the LED Light becomes solid GREEN,
indicating that charging is complete.
5. Disconnect charger from collar unit and securely replace the
Charging Port Cover.
NOTE - A solid ORANGE LED light after 7 hours of charging indicates an
error in charging (see pg. 22). Try charging the collar unit again.
