D-Link DAP-1325 User Manual

DAP-1325 N300 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
Parameter Description
Enable periodic
scanning
Move the switch to the right to let the extender search for a free
channel in certain periods of time. When the switch is moved to the
right, the Scanning period field is available for editing.
Scanning period
Specify a period of time (in seconds) after which the extender
rescans channels.
When you have configured the parameters, click the APPLY button.
To edit the settings of the basic wireless network, in the Access Points section, left-click the
needed network. On the opened page, change the needed parameters and click the APPLY button.
Also you can create an additional wireless network. To do this, click the ADD button in the
Access Points section. On the opened page, specify the relevant parameters.
Figure 44. Creating a wireless network.
Page 50 of 92

D-Link DAP-1325 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA2, WPS-PBC
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN (RJ-45) ports	1
Certification	FCC, IC, CE, RCM, IDA, CB, LVD, UL, WPS
Product color	Grey, White
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	RoHS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	97 g
