D-Link DAP-1325 User Manual

DAP-1325 N300 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
Advanced
In this menu you can add name servers.
DNS
On the Advanced / DNS page, you can add DNS servers to the system.
Figure 57. The Advanced / DNS page.
DNS servers are used to determine the IP address from the name of a server in Intranets or the
Internet.
On this page, you can specify the addresses of DNS servers manually.
If you want to specify the DNS server, click the ADD SERVER button (use the Name Servers
IPv4 section for IPv4 and the Name Servers IPv6 section for IPv6) and enter a DNS server
address. Then click the APPLY button.
To remove a DNS server from the page, click the Delete icon ( ) in the line of the address and
then click the APPLY button.
If needed, you can add your own address resource record.
3
To do this, click the ADD button.
Figure 58. The window for adding a DNS record.
3 You need to specify the IP address of the extender as a DNS server for clients of the DAP-1325 device to allow them
to use the records.
Page 72 of 92

D-Link DAP-1325 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA2, WPS-PBC
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN (RJ-45) ports	1
Certification	FCC, IC, CE, RCM, IDA, CB, LVD, UL, WPS
Product color	Grey, White
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	RoHS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	97 g
