D-Link DAP-1325 User Manual

DAP-1325 N300 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
IPv6
Go to the IPv6 tab to change IPv6 address of the extender and configure IPv6 addresses assignment
settings.
Figure 41. Configuring local IP addresses. The IPv6 tab. The IP section.
If needed, edit the basic settings.
Parameter Description
IP
Addressing Mode
Select the needed value from the drop-down list.
Static: an IPv6 address and a prefix are specified manually.
Prefix delegation: the extender requests a prefix to configure an
IPv6 address from a delegating router.
IP address
The IPv6 address of the extender in the local subnet. By default, the
following value is specified: fd01::50. The field is available for
editing, if the Static value is selected from the Addressing Mode
drop-down list.
Prefix
The length of the prefix subnet. By default, the value 64 is
specified. The field is available for editing, if the Static value is
selected from the Addressing Mode drop-down list.
Page 47 of 92

D-Link DAP-1325 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA2, WPS-PBC
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN (RJ-45) ports	1
Certification	FCC, IC, CE, RCM, IDA, CB, LVD, UL, WPS
Product color	Grey, White
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	RoHS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	97 g
