D-Link DAP-1325 User Manual

DAP-1325 N300 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
Local Update
!
Attention! Do not turn off the extender before the firmware update is completed. This
may cause the device breakdown.
To update the firmware of the extender locally, follow the next steps:
1. Download a new version of the firmware from www.dlink.ru.
2. Click the CHOOSE FILE button in the Local Update section on the System /
Firmware Update page to locate the new firmware file.
3. Click the UPDATE FIRMWARE button.
4. Wait until the extender is rebooted (about one and a half or two minutes).
5. Log into the web-based interface using the login (admin) and the current password.
If after updating the firmware the extender doesn't work correctly, please restore the factory default
settings. To do this, click the Factory button on the System / Configuration page. Wait until the
extender is rebooted.
Page 80 of 92

D-Link DAP-1325 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA2, WPS-PBC
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN (RJ-45) ports	1
Certification	FCC, IC, CE, RCM, IDA, CB, LVD, UL, WPS
Product color	Grey, White
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	RoHS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	97 g
