D-Link DAP-1325 User Manual

DAP-1325 N300 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
In the opened window, you can specify the following parameters:
Parameter Description
Enable rule
Move the switch to the right to enable the rule.
Move the switch to the left to disable the rule.
Action
Select an action for the rule.
Deny: Blocks access to the extender or the upper router's network
for the device with the specified MAC address if the default mode
allows access for all devices.
Allow: Allows access to the extender or the upper router's network
for the device with the specified MAC address if the default mode
denies access for all devices.
MAC address
The MAC address of a device connected to the extender.
After specifying the needed parameters, click the SAVE button.
To edit a rule, select the relevant line in the table. In the opened window, change the needed
parameters and click the SAVE button.
To remove a rule, select the checkbox located to the left of the relevant line of the table and click
the Delete button. Also you can remove a rule in the editing window.
Page 75 of 92

D-Link DAP-1325 Specifications

General

Type	Network repeater
WPS push button	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA2, WPS-PBC
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN (RJ-45) ports	1
Certification	FCC, IC, CE, RCM, IDA, CB, LVD, UL, WPS
Product color	Grey, White
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	RoHS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	50.7 mm
Width	97.9 mm
Height	48.7 mm
Weight	97 g
