D-Link DAP-1360U

DAP-1360U Wireless N300 Access Point & Router
User Manual
Overview
Product Appearance
Top Panel
Figure 1. Top panel view.
LED Mode Description
POWER
Solid green
The device is powered on.
No light
The device is powered off.
WLAN
Solid green
The device's WLAN is on.
Blinking green
Data transfer through the Wi-Fi network.
No light
The device's WLAN is off.
WPS
Blinking green
Attempting to add a wireless device via the WPS
function.
No light
The WPS function is not in use.
INTERNET
Solid green
The cable is connected to the port.
Blinking green
Data transfer through the WAN port.
No light
The cable is not connected.
LAN 1-4
Solid green
A device (computer) is connected to the relevant port,
the connection is on.
Blinking green
Data transfer through the relevant LAN port.
When the access point is being loaded, the LEDs are
blinking one at a time.
When the firmware is being upgraded, the LEDs are
blinking two at a time.
No light
The cable is not connected to the relevant port.
Page 9 of 158
