D-Link DCS-930L User Manual

63D-Link DCS-930L User Manual
Appendix B - Networking Basics
Networking Basics
Check your IP address
After you install your new D-Link wireless adapter and have established a wireless connection, by default, the TCP/IP settings should be set to obtain
an IP address from a DHCP server (i.e., router) automatically. To verify your IP address, please follow the steps below.
Windows® 8 Users
• Press the Windows key and R together. Type cmd in the box
and click OK.
• At the prompt, type ipcong and press Enter.
• This will display the IP address, subnet mask, and default
gateway of your adapter.
Windows® 7/Vista® Users
• Click Start, type cmd in the search box and then click OK.
• At the prompt, type ipcong and press Enter.
• This will display the IP address, subnet mask, and default
gateway of your adapter.
If the address is 0.0.0.0, check your adapter installation, security settings, and the settings on your router. Some rewall software programs may
block a DHCP request on newly installed adapters.

D-Link DCS-930L Specifications

General

Maximum resolution	640 x 480 pixels
White balance	Auto
Minimum illumination	1 lx
Sensor type	CMOS
Optical sensor size	1/5 \
Digital zoom	4 x
Security algorithms	WEP, WPA, WPA2
Video motion detection	Yes
Cabling technology	10/100Base-T(X)
Supported network protocols	IPV4, ARP, TCP, UDP, ICMP, DHCP, NTP, DNS, DONS, SMTP, FTP, HTTP, PPPoE, UPnP, LLTD
AC input voltage	100-240 V
DC output current	1.2 A
DC output voltage	+5V
AC input frequency	50 - 60 Hz
Power over Ethernet (PoE)	-
Power consumption (typical)	2 W
Ethernet LAN (RJ-45) ports	1
Certification	FCC B, IC, C-Tick, CE
Placement supported	Indoor
Dimensions (WxDxH)	27.2 x 60 x 96 mm
Compatible operating systems	Windows XP / Vista / 7
Flash memory	4 MB
Internal memory	32 MB
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Form factor	Cube

Weight and Dimensions

Weight	76.9 g
